Small in size with height of 137mm, using 92mm fan.
Powerful performance, Compact fin design + powerful fan makes it capable to support chipsets up to TDP 130W.
Offcenter heatsink structure to avoid interference with RAM.
4*Ф6 mm heatpipes directly in contact with CPU, absorbing and dissipating the heat more efficiently.
Special backplate bracket and metal adapter frame makes the mounting easy and structure strong.
Asymmetric twin-tower heatsink enhances heat dissipation and improves airflow efficiency.
Shark-tooth design & nickel-plating provide an awesome gamer's vibe.
Dual FDB & rubber-coated PWM-capable fans provides longer lifespan and reduced noise.
Both fans have a minimum speed of 300 RPM to provide the ultimate zero-noise operation.
8 U-shaped copper heatpipes to achieve the best cooling performance.
Solid bending designs maximize the efficiency of thermal conductance.
Highly-polished copper base that makes a perfect contact with the CPU surface to achieve optimal cooling performance.
Equipped with multiple clips to support Intel LGA2011 -V3/LGA2011/1366/1156/1155/1151/1150/775 and AMD AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
AMD AM4 Ready. (NOTE: Refer to FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2 for the manuals)
Equipped with multiple clips to support Intel LGA1366/1156/1155/1151/1150/775 and AMD AM4/FM2/FM1/AM3+/AM3/AM2+/AM2/K8.
3 sintered metal powder heatpipes directly contacting the CPU surface for removing heat and eliminating chances of overheating.
Ф120 x 25 mm PWM-capable fan offers perfectly balances powerful airflow and reduced noise.
Can be easily installed without moving the motherboard.
Excellent cooling performance up to 130 W.
* Optional: Socket LGA2011.



Application For






Technical Spec

Product Dimensions

126X134X158 mm

Heatsink Dimensions

120X108X158 mm

Net Weight

1000 g


Ø6 mm×6 pcs

Fan Dimensions


Fan Speed

900~1500 RPM±10% | 1300 PWM±10%

Fan Airflow

74.34 CFM | 65.16 CFM

Fan Air Pressure

1.53 mmAq | 1.18 mmAq

Fan Noise

≤30 dB(A) | ≤26.1 dB(A)

Fan Connector

4-pin PWM | 3-pin

Bearing Type

Hydro Bearing

Fan Rated Voltage


Fan Rated Current

0.18 A | 0.2 A

Fan Power Consumption

2.16 W | 2.4 W

LED Type

White LED
