DeepCool NEW ARK 90

Article: 02481
Out of stock
In stock
Shipping methods
  • Pickup from New Mail
  • New Mail Courier
  • Pickup from the store
  • Other transport services
Payment methods
  • Cash upon receipt
  • Bank transfer
Description

Application For

Intel

LGA20XX/LGA1366/LGA115X


High End Desktop i9/i7
Core i7/i5/i3
Pentium G
Celeron G
AMD

AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1


Ryzen
APU A12/A10/A8/A6/A4
FX 8/6/4-Core
Phenom II X6/X4/X3/X2
Athlon II X4/X3/X2
Athlon X4

Technical Spec


Motherboards E-ATX/ATX/M-ATX/Mini-ITX (MAX 305×276mm)
Materials SGCC+Plastic (ABS)+Tempered Glass (Panel thickness: 0.8~1.0mm)
Product Dimension (LxWxH) 530×232×545.5mm
Net Weight 14.34kg
Gross Weight 17.77kg
5.25" Drive Bays 0
3.5" Drive Bays 3
2.5" Drive Bays 3+3
I/O Panel 2×USB3.0 /Audio(HD)×1/Mic×1/Manual Controller for RGB
Expansion Slots 8 (plus 2 extra slots for vertical VGA card installation)
Cooling Fans Support Pre-installed: Rear: 1×140mm RGB fan; Side: 3×140mm RGB fan; Optional: Top:3×120mm fan; Front: 3×120mm fan
Power Supply Support ATX PS2 (maximum length: 200mm)
CPU Cooler Compatibility 186mm height limit Liquid Cooler: Front: 120/240mm or 360mm (Remove HDD cage); Top: 120/240/360mm; Rear: 120/140mm
Graphic Card Clearance 310mm(Horizontal mounting)/400mm(Vertical mounting)
Carton Dimension 625×335×627mm(L×W×H)
Water Block Dimensions 92.5×93×85mm(L×W×H)
Radiator Dimensions 330×125×28mm(L×W×H) (aluminum material)
Fan Dimensions 140×140×25mm RGB Fan×4pcs
Fan Speed 500±200-1800±10%RPM (4Pin)
Fan Air Flow 90.14 CFM (MAX) Each 140mm Fan
Fan Noise Level 17.6~35.3dB(A)
Fan Bearing Type Hydro Bearing
Fan Rated Voltage 12VDC
Fan Rated Current 0.44±10%A(MAX) Each Fan (Including RGB lights)
Fan Power Consumption 5.28W Each
Pump Connector 3Pin
Pump Operating Voltage 6~13.8VDC
Pump Rated Voltage 12VDC
Pump Speed 2300±10%RPM
Pump Current 0.2A(MAX)
Pump Power Consumption 2.4W
EAN 6933412713425
P/N DP-ATXLCS-NARK90BK
