V2801D-1GT1

Article: 03529
V2801D-1GT1
VSOL
Leave review
Out of stock
In stock
Shipping methods
  • Pickup from New Mail
  • New Mail Courier
  • Pickup from the store
  • Other transport services
Payment methods
  • Cash upon receipt
  • Bank transfer
Description Reviews
Description

G/EPON 1GE+CATV ONU is support Dual mode(EPON and GPON), It can also be applied to a wide temperature environment, and also has a powerful firewall function.

G/EPON 1GE ONU meets telecom operators FTTO (office), FTTD (Desk), FTTH(Home) broadband speed, SOHO broadband access, video surveillance and other requirements and design a GPON/EPON Gigabit Ethernet products. The box is based on the mature Gigabit GPON/EPON technology, highly reliable and easy to maintain, with guaranteed QOS for different service. And it is fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.

Характеристики ONU V2801D V-solution 1GE+CATV

►  Dual mode(Can access EPON/GPON OLTs)
►  Compatible with popular OLT(HW,ZTE…)
►  Industrial Design
►  Routing or Bridging Mode
►  Detecting Rogue ONU
►  Flow & Storm Control , Loop Detection
►  Firewall: DDOS, Filtering Based on ACL/MAC/URL
►  O&M: WEB/TELNET/OAM(OMCI)/TR069

   Technical parameters
Technical item 1GE+CATV ONU
PON interface 1 G/EPON port(EPON PX20+ and GPON Class B+)

Wavelength:Tx1310nm,Rx 1490nm

SC/UPC connector

Receiving sensitivity: ≤-28dBm

Transmitting optical power: 0~+4dBm

Transmission distance: 20KM
LAN interface 1 x 10/100/1000Mbps auto adaptive Ethernet interfaces.10/100/1000M Full/Half, RJ45 connector
LED 3, For Status of REG、SYS、LINK/ACT
Operating condition Temperature: -30℃～+70℃

Humidity: 10%～90%（non-condensing）
Storing

condition

 Temperature : -30℃～+70℃

Humidity :10%～90%（non-condensing）
Power supply DC 12V/0.5A(option)
Power consumption ≤4W
Dimension 82mm×82mm×25mm（L×W×H）
Net weight 85g



Software Key Feature
EPON/GPON mode Dual mode , Can access EPON/GPON OLTs.
 Software mode Bridging mode and Routing mode.
 Abnormal protection Detecting Rogue ONU, Hardware Dying Gasp.
 Firewall DDOS, Filtering Based on ACL/MAC/URL.
 Layer2 802.1D&802.1ad bridge, 802.1p Cos, 802.1Q VLAN.
 Layer3 IPv4/IPv6, DHCP Client/Server , PPPoE, NAT , DMZ ,DDNS.
 Multicast IGMP v1/v2/v3 , IGMP snooping.
 Security Flow & Storm control, Loop Detection.
 O&M WEB/TELNET/OAM/OMCI/TR069.
