Tenda CP3 Pro

      Camera

Image Sensor

  1/3 Progressive Scan CMOS sensor

Day and Night

  ICR type

      Lens

Focal Length

  4mm

Aperture

  F2.0

FOV

  Horizontal : 78°, Vertical : 41.8°, Diagonal : 95°

      Illuminator

Supplementary Light

  2 IR Lights

Supplementary Light Distance

  Up to 10 m/32 ft (depending on environment)

IR Wavelength

  850nm

Night Vision Mode

  Black & White Mode

      Video

Video Encoding Format

  H.265, H.264

Main Stream Resolution

  2304 × 1296, 1920 × 1080, 1280 × 720

Sub Stream Resolution

  640 x 360 , 352 x 288 , 320x240

Frame Rate

  1-30fps, Default 20fps

Bit Rate

  512kbps -- 4096kbps

Bit Rate Control

  CBR,VBR

      Audio

Audio  Encoding Format

  G.711A, G.711U, AAC

Audio Sampling Rate

  8 kHz

Audio Communication

  Two-way Audio, One-touch Call


Image Enhancement

  DWDR, BLC, HLC, 3D DNR

Privacy Mask

  4 Areas

      Network

ONVIF

  Support

Protocols

  TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP

      Pan&Tilt

Pan Movement Range

  0°--355°

Tilt Movement Range

  -65°--90°

Preset

  6

Patrol

  Panoramic Patrol, Preset Patrol

      Wi-Fi

Antenna

  Internal antenna

Wireless Standard

  IEEE 802.11 b/g/n/ax

Transmission Rate

  Up to 287Mbps

Channel Width

  20/40 MHz

Modulation

  DSSS/OFDM/OFDMA

Frequency Band

  2.4GHz: 2412MHz-2472MHz(CH1-CH13)

Transmit Power

  2.4GHz: <0.1W(EIRP)

Security

  64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

      Alarm

Smart Detection

  Motion Detection, Tempering Detection, Human Detection, Cry Detection, Pet Detection

Smart Linkage

  Sound&light Alert, Human Tracking

DIY Audio

  3 Customized Audios

      Interface

Audio Input

  Built-in MIC, adjustable microphone volume

Audio Output

  Built-in Speaker, 68 dBA (Alarm sound at 1 meter), adjustable sound level

Storage

  Built-in Micro SD Card Slot, Up to 256 GB

Reset Button

  Support

LED Indicator

  Dual Color (red & blue)
   LED Indicator

      General

Power

  9V DC, 1A, Ø5.5mm&Ø2.1mm Power Plug

Material

  Plastic

Smart Integration

  Amazon Alexa

Product Dimension

  103mm x 88mm x 88mm (4.1'' × 3.5'' × 3.5'')

Package Dimension

  100mm x 100mm x 163mm (4.0'' × 4.0'' × 6.5'')

Product Weight

  200g (0.44lb)

With Package Weight

  420g (0.93lb)

Installation Method

  Desktop, Ceiling Mounting

Certification

  CE, RoHS, FCC, RCM, UKCA

Temperature

  Operating Temperature: -10°C ~ 45°C (14°F ~ 113°F)
  Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)

Humidity

  Operating Humidity: 10% ~ 95% RH (non-condensing)
  Storage Humidity: 3% ~ 95% RH (non-condensing)

Package Contents

  Camera
  Power Adapter (cord length: 3m)
  Installation Template
  Mounting Bracket
  Mounting Accessories Kit
  Quick Installation Guide
